Baileigh R-M55H Manual Roll Bender

Baileigh R-M55H Manual Roll Bender

The R-M55H profile bender's design was developed from the R-M55.

• It has the same 2" schedule 40 pipe capacity, but incorporates an industrial-grade hydraulic system to control the top forming roll. This takes less effort and time for the operator to achieve the same radii.
• In addition to the hydraulic movement, there is also a digital readout to let the operator know exactly where the top shaft is positioned. This is very important for repeating bends.
• The R-M55H has a powerful, direct gearbox drive system that delivers full torque when bending at full capacity.
• The R-M55H uses an inverter that is overload protected, to control the rolling speed.
• Being variable speed allows the operator to fine tune the rolling speed for each material.
• Running on just 220 volt, single phase power to operate, can bend while both in a vertical position, for small rolling projects, or horizontally, for larger rolling projects.
• Operation of the R-M55H profile bender is done from a portable pedestal that has a digital readout, controls for the top roll positioning, and foot pedal controls for forward and reverse of the rollers.
• This profile bender is designed to offers years of production at a very affordable price.
• Foot pedal operation
• 60mm dia' 2.1mm round tube capacity
• Single pinch
• Double driven rolls

• Item Number R-M55H
• Country of Manufacture Portugal
• Driven Rolls 2
• Roll Adjustment Hydraulic
• Pipe Capacity Size: 60 (4) mm / Min. Dia: 1,016 mm
• Round Tube Capacity Size: 70 (2.1) mm / Min. Dia.: 1,524 mm
• Square Tube Capacity Size: 50 (2.1) mm / Min. Dia.: 1,219 mm
• Solid Round Capacity Size: 35 mm / Min. Dia.: 508 mm
• Flat Bar Easy Way Size: 101 (12.7) mm / Min. Dia.: 508 mm
• Flat Bar Hard Way Size: 128.5 (9.5) mm / Min. Dia.: 508 mm
• Angle Iron Capacity Size: 50 (6.3) mm / Min. Dia.: 711 mm
• Shaft Diameter 50 mm
• Shaft Center Distance 13.12″
• Upper Roll Dia. 148 mm
• Lower Roll Dia. 148 mm
• Motor 1.5 hp
• Pinch Single
• Power 220V / single-phase
• Shipping Weight 453 kgs.
• Material Type All Specs based on 60,000 PSI (42 Kg/mm 2) Tensile Strength – Mild Steel.
• *Optional Tooling Some applications may require optional tooling.
• Speeds 5754
• Shipping Dimensions (Inches) 1524 x 1118 x 1727 mm
